Mahindra XUV 500 User Manual

© Copyright Mahindra and Mahindra Ltd. 052016
2-19
2.6 Technical Specifications
Technical Specifications
ENGINE - mHawk
Displacement/Cubic Capacity
2179 cc
Type 4 Stroke, Turbocharged, DI engine
Compression Ratio
15.5 : 1
Max. Engine Output (kW @ rpm) 103 kW @ 3750 rpm
Max. Torque (Nm @ rpm) 330 Nm @ 1600 to 2800 rpm
TRANSMISSION
Type 6 Speed Synchromesh
No. of Gears
6 Forward, 1 Reverse
GEAR RATIOS
Transaxle Ratio Final Drive Ratio Overall Ratio
I 4.15 4.263 17.69
II 2.14 4.263 9.123
III 1.24 4.263 5.286
IV 0.95 4.263 4.049
V 1.02 3.24 3.33
VI 0.87 3.24 2.819
Reverse 4.96 3.24 16.07
STEERING
Type/Description Hydraulic, Rack and Pinion, Power Assisted
Steering Wheel Diameter
380 mm
GENERAL
