MAIOR Levante - Dimensions and Technical Data

IT
8
1.3.3. Dimensions and technical data
Template
LEVANTE
dimensional data
Minimum height [mm]
842.5
Height [mm]
1901.5
Depth [mm]
185
maximum ascent speed [mm / s]
38
Vacuum Total weight [kg]
33
Electrical system
Power circuit [V]
220/110
Frequency [Hz]
50/60
flow
Maximum TV Capacity (including accessories) [kg]
30
Maximum TV Size
65 "900mm or until the short
side
Maximum covering panel capacity [Kg]
10
Figure 3: Dimensions
The adjustable support of the cover ⑤ panel allows an adjustment in the vertical direction,
independent of the column, 60mm
