1.3.4. Linak Actuator DL12XL
Features:
• Max. Thrust: 600 N
• Max. Speed: 38 mm / s
• Max bending moment: M max = 100 Nm dynamic
• Piezo ™: Anti-collision sensor
• PVC-Free ™
• Silent movement
use:
• Duty cycle: 5%
• Operating temperature: from + 10 ° to +40 ° C
• transport and storage temperature: -10 ° C to + 70 ° C
• approved system in accordance with EN 60335-1, UL 962 with CBD6S
Figure 4Column DL12XL
1.3.5. motor lead
Figure 5: Motor lead
The motor must be connected to the control unit via the supplied cable. The motor should not be connected
directly to the mains, it will invalidate the guarantee.
1.3.6. CDB6S unit
Features
• Power: 300W
• Power supply: 230V AC, 50Hz, or 120V AC, 60Hz
• Unit SMPS (Switch Mode Power Supply)
• Protection Electronic against overloads (EOP)
• Function soft start / stop
