Minimum distance: Pair cable, Coaxial Cable or
Cable Tester >5m
Maximum distance: Depends upon the V.O.P of the
cables under test.
3.0km @ V.O.P. ≤99.9%
2.4km @ V.O.P. ≤80.0%
2.0km @ V.O.P. ≤66.0%
1.5km @ V.O.P. ≤50.0%
Range Selection: Automatic range control
Resolution: 0.1m
Accuracy: ± [2% of reading ±0.2m] < 100m
± [2% of reading ±0.5m] ≥ 100m
Impedance Selection: Automatic output impedance
control
Velocity Factor: Adjustable from 1.0% to 99.9%
Cable Library: 20 standard cable types
Memory Location: 99 for custom cable types
Connector Type: BNC, RJ45
Batteries: 2 LR6 (AA) type 1.5V alkaline
Operating Temperature: 0°C to 40°C (32°F to 104°F)
Storage Temperature: -10°C to 50°C (14°F to 140°F)
Relative Humidity: 0% to 80%RH
Size (H X W X D): 152 X 61 X 34mm
Weight: 227,9g
General Specifications
Function
Range
