Major tech MTD75T User Manual

Function
Range
Resoluti
on
Accuracy
(% of reading + digits)
DC
Voltage
600mV
0.1mV
±1.0% of rdg ± 5 digits
6.00V
1mV
±0.5% of rdg ± 5 digits
60.0V
10mV
600V
100mV
Input impedance 10MΩ. Overload protection 1000Vrms
Function
Range
Resolution
Accuracy
(% of reading +
digits)
Resistance
600.0Ω
0.1Ω
±0.8% of rdg ±
5digits
6.000kΩ
1Ω
±0.8% of rdg ± 1
digits
60.00kΩ
10Ω
600.0kΩ
100Ω
6.000MΩ
1kΩ
60.00MΩ
10kΩ
±1.0% of rdg ± 5
digits
Input Protection: 250V dc or 250V ac rms
Note: a. On 600Ω range, short the test leads to measure lead
resistance, then subtract the value from the real measurement
b. When measuring resistance over 1MΩ, it is normal that the
reading reacts slowly, wait until reading is stable
