Major 8400 - Page 34

30 www.major-equipment.com
12FT3PL Rollermower - Body - Parts Listing
11 123RMA01 HEAVY A-FRAME 1
12 1/2F 1/2” FINE NYLOC NUT 32
13 12FTHRAS THREADED HEIGHT ADJUSTER 4
14 12GMRA2L HEIGHT ADJUSTER (LH) 1
15 12GMRA2R HEIGHT ADJUSTER (RH) 1
17 190.000.545 PTO GUARD (EXTENDED OVAL) 1
18 LF205T21 6-21 SPLINE “T” BOX RATIO 1.47 2
19 5/8F 5/8” FINE NYLOC NUT 16
20 58x214FBZP 5/8”x2 1/4” FINE BOLT 8
21 8SM14 DIA 1 1/4” BUSHx1 3/4” 4
22 FW12 12” FLAT WASHER 4
23 FWM8 M8 FLAT WASHER 4
24 FWM16 M16 FLAT WASHER 4
25 FWM20 M20 FLAT WASHER 8
26 M12 M12 NYLOC NUT 16
27 M12x100BZP M12x100 BOLT 4
28 M12x120BZP M12x120 BOLT 4
29 M12x40BZP M12x40 BOLT 4
30 M12x60BZP M12x60 BOLT 4
31 M16 M16 NYLOC NUT 2
32 M20 M20 NYLOC NUT 2
33 M20HEX M20 PLAIN NUT 4
34 M20x150BZP M20x150 BOLT 2
35 M8x16SZP M8x16 SET BOLT 4
36 MOT75 DIA 105x75 BUFFER 2
37 NT55A RUBBER COUPLING 4
38 RM-M20C ROLLER ADJUSTER CAP NUT 4
39 RMORA-1 OFFSET HEIGHT ADJUSTER (RH) 1
40 RMORA-2 OFFSET HEIGHT ADJUSTER (LH) 1
41 112 CAT 2 PIN DIA 28.5x159mm 2
42 3546 LINCH PIN DIA 9.5 2
43 849 GREASE NIPPLE M6 STR 4
44 SW58 5/8” SPRING WASHER 12
45 T292B 6 SPLINE “T” BOX RATIO 1.86 1
46 12EW45-2 (EW45/2) 21 SPLINE STAR DRIVE 2
47 12T-BBS BLADE BACK SPACER 4
48 17FT54SH 54mm SPLIT HUB 4
49 17FT-SHC SPLIT HUB COLLAR 8
50 RM-RSN3 SHAFT COLLAR DIA 35 4
51 T292A-S1 T292 G/BOX STUD 8
52 12B-USL 12ft BODY UNDERSIDE COVER 1
53 12GMTC-2 12000 BODY COVER 1
54 12RM-RD-RB BODY REAR DEFLECTOR 1
55 12RM-RD-RBH BODY REAR DEFLECTOR 1
56 12TC-E G/BOX COVER END 2
57 GM6-4F GEARBOX REINF” 2
58 RM-RSN2 ROLLER MOUNT 4
59 RM-RSN4 SCRAPER MOUNT 4
60 12x3FSKS 1/2”x3” FINE SOCKET HEAD 12.9 32
Item Part No Description Qty
