25 LC360 LAMP 2
26 M12 M12 NYLOC NUT 17
27 M12x120BZP M12x120 BOLT 4
28 M12x30SZP M12x30 SET BOLT 4
29 M12x35BZP M12x35 BOLT 9
30 M16 M16 NYLOC NUT 2
31 M16x75BZP M16x75 BOLT 2
32 M20 M20 NYLOC NUT 10
33 M20x110BZP M20x110 BOLT 4
34 M20x130BZP M20x130 BOLT 2
35 M20x150BZP M20x150 BOLT 4
36 M24 M24 NYLOC NUT 2
37 15501 CAT 0 PIN DIA 16x97mm 3
38 3546 LINCH PIN DIA 9.5 4
39 37 LINCH PIN DIA 6 3
40 4418 CAT 0 TOP LINK 2
41 820 GREASE NIPPLE 1/8” STR 4
42 849 GREASE NIPPLE M6 STR 4
43 8561 TOW EYE BUSH 1
44 16WTD010 DRAWBAR PIVOT PIN 2
45 TA-LGPLITL LGP LIGHT BRACKET (LH) 1
46 TA-LGPLITR LGP LIGHT BRACKET (RH) 1
51 98611210CE00900700 WIDE ANGLE V60 FIXED SLIP 1
12000GR, 17000GR & 18000GR Rollermowers
Item Part No Description Qty
1 12DB001 ROLLERMOWER DRAWBAR 1
2 12DB-020 DRAWBAR STOP 2
3 12DB-030 PTO STAND 1
4 12GMASS1 AXLE RAM STOP 1
5 12GMJK-1 RM PARKING JACK 1
6 12RM-BGA-07 12000 RM BODY ASSY 1
7 12RM-WGA-07 12000 WING (RH) 1
8 12W-PIN07 PIVOT PIN 4
9 17GMA1 17RM AXLE FAB 1
10 8T12 AXLE CLAMP 2
11 RTE-01 ROTARY HITCH EYE 1
12 T50-12W 12000 WING PTO SHAFT 2
13 12D-RAM03_B DRAWBAR RAM 2
14 12D-RAM_B AXLE RAM 1
15 17GM-WR4_B WING LIFT RAM 2
16 26120012 DIA 650x320mm 2
17 8SM14 DIA 1 1/4” BUSHx1 3/4” 4
18 FW114 DIA 1 1/4” FLAT WASHER 4
19 FW12 12” FLAT WASHER 4
20 FWM12 M12 FLAT WASHER 1
21 FWM16 M16 FLAT WASHER 4
22 FWM20 M20 FLAT WASHER 18
23 FWM24 M24 FLAT WASHER 2
24 LC2700 TRIANGLE REFLECTOR 2
Item Part No Description Qty
