SWIFT
MJ71-190/240
MJ71-190FM/240FM
MJ71-340/400/540
MJ71-340T/400T/540T
MJ71-400FM
MJ71-600T/730T
SWIFT
Operators Manual & Parts List

Table of Contents

Questions and Answers:

Major SWIFT MJ71-190FM Specifications

General IconGeneral
BrandMajor
ModelSWIFT MJ71-190FM
CategoryLawn Mower
LanguageEnglish

Summary

Introduction

Safety Aspects

Key safety information and precautions for operating the machine.

Intended Use

Specifies the machine's designed purpose and prohibited uses.

Register Your Product and Warranty Online

Instructions for product registration and warranty details.

Tractor Requirements

Attaching the Machine to the Tractor

Guidance on connecting the machine to the tractor for stability and maneuverability.

Recommended Horse Power Requirements

Details on suitable tractor horsepower for optimal performance and safety.

Safety

Hazards Associated with Operating Grass Cutting Machinery

Identifies potential hazards like shear, crush, pinch, and wrap points.

Free-wheeling Parts Hazard

Risks associated with components continuing to rotate after power shut-off.

Thrown Objects Hazard

Hazards from foreign objects expelled by the machine at high speed.

Hydraulic Hazard

Safety precautions for high-pressure hydraulic systems and leaks.

Slips, Trips and Falls Hazard

Common causes and prevention methods for slips and falls.

Noise Hazard

Information on noise levels and the importance of hearing protection.

Operating Safely

General safety practices, including clothing, PPE, and machine operation rules.

Workstation

Operator position and safety

Rules for operator seating and ensuring PTO is off before leaving the tractor.

Regulations for use of the transmission

Transmission guarding and safety

Importance of proper guarding and avoiding entanglement with moving parts.

PTO Shaft Safety

Maximum PTO input and shaft replacement

Guidelines on PTO input limits and replacing PTO shafts.

PTO shaft length adjustment

Detailed steps for shortening PTO shafts to ensure correct engagement.

Driving Safely on Public Roads

Highway Code regulations and indicators

Checks for highway compliance, reflectors, and load indicators.

Bystander safety during transport

Rules to keep bystanders clear of the machine during operation and transport.

Transport speed limits for trailed models

Maximum allowed transport speed for the implement.

General safety instructions

Precautions before operating

Rules on operator condition, area clearance, and disconnecting PTO.

Inspections before Use

Pre-operation checks

Checklist for oil levels, lubrication, parts wear, and guards.

Starting Regulations

PTO shaft locking and safety

Ensuring PTO shaft yokes are locked to prevent slippage and injury.

Product Identification

Machine Serial Numbers

Importance of recording model and serial numbers for service and parts.

Product Specifications

Machine specifications table

Detailed technical data for various MJ71 models.

EEC certificate of conformity

Manufacturer declaration and compliance

Statement of conformity with essential health and safety requirements.

Machine Safety Labels

Safety alert symbols and meanings

Explanation of DANGER, WARNING, CAUTION labels and safety alert symbols.

General safety labels

Visual examples of safety labels for various hazards.

PTO related labels

Labels for maximum PTO input and PTO shaft alignment.

Lubrication and moving parts labels

Labels indicating grease points and moving parts hazards.

Key to Main Parts

Labeled diagrams of machine components

Visual identification of major machine parts with numerical references.

Blade Rotation

Underside view of blade rotation patterns

Diagrams showing the direction of blade rotation for different models.

Blade system

Breakdown of blade assembly components

Detailed illustration of blade mounting and related parts.

Drive-line gearboxes

Primary and Rotor gearbox identification

Visuals and labels for primary and rotor gearboxes.

Attaching machine to the Tractor

Safety precautions during hitching

Essential safety rules for hitching and unhitching the implement.

Three Point Linkage Models attachment

Step-by-step guide for attaching via 3-point linkage.

Trailed Models attachment

Step-by-step guide for attaching trailed models.

Transport Position

Safety before raising machine

Instructions to wait for components to stop before raising the machine.

Transport locking bars and stoppers

Importance of using locking bars for winged models to relieve hydraulic pressure.

Transport speed limits for trailed models

Maximum allowed transport speed for the implement.

Operating the Machine/Mowing

Safety during mowing operations

Warnings about limbs under the machine and PTO engagement.

Mowing procedure

Step-by-step guide for hitching, connecting PTO, and starting mowing.

Top Link position (flotation restrictor)

Setting top links for flotation

Instructions for adjusting top links to limit wing lift and prevent damage.

Roller and Castor wheels adjustment

Castor wheels adjustment

Steps to adjust castor wheel height for desired cutting.

Roller height adjustment

Procedure for adjusting roller height on both sides of the machine.

Scraper bar

Scraper bar tensioning and adjustment

How to tension the scraper bar and adjust its bracket position.

Maintenance

General maintenance requirements

Importance of regular maintenance by competent persons using genuine parts.

Machine storage

Recommendations for proper storage

Guidelines for storing the machine in a dry environment and preparing it.

PTO Shaft Maintenance

Guard removal and yoke end greasing

Steps for removing the guard and greasing PTO yoke ends.

PTO Greasing Intervals

Schedule for greasing PTO components based on operating hours.

Shearbolt Replacement

Procedure for replacing shearbolts and fitting PTO shafts correctly.

Transmission Bolts

Checking transmission bolt tightness

Intervals for checking and tightening transmission bolts after mowing.

Roller (if applicable)

Roller end bearing check

Checking roller end bearing condition and adjusting tightness.

Replacement of wear parts

Blade and wear part inspection/replacement

Guidance on checking and replacing blades, bolts, and other wear parts.

Wheel and tyre checks

Daily checks for wheel nuts, tyre pressure, and tyre wear.

Blade rotation and timing check

Importance of checking blade rotation and timing after servicing.

Component weight and support

Warning about the weight of components and the need for adequate support.

Clearing out a blockage

Procedure for clearing blockages

Steps to clear blade blockages, including transport position and pressure washing.

Wing shafts alignment (if applicable)

Correct alignment for wing PTO shafts

Ensuring correct alignment of wing PTO shaft yokes to prevent damage.

Troubleshooting

Machine getting blocked

Causes and remedies for the machine getting blocked by material.

Streaks of uncut grass

Causes and remedies for leaving streaks of uncut or partially cut grass.

Uneven material discharge

Causes and remedies for uneven material discharge and bunching.

Gearbox overheating

Causes and remedies for gearbox overheating.

Blade scalping ground

Causes and remedies for blades scalping the ground.

Blades wear too fast

Causes and remedies for rapid blade or bullet wear.

Excessive power requirement

Causes and remedies for the mower requiring excessive power.

Excessive vibration

Causes and remedies for excessive vibration.

Noisy machine

Causes and remedies for a noisy machine.

Gearbox leaking

Causes and remedies for gearbox oil leaks.

Lubrication schedule

Grease and oil points and intervals

Schedule for greasing and checking oil levels in various machine components.

MJ71-190 Spare Parts

MJ71-190 General Assembly diagram

Exploded view of the MJ71-190 general assembly with numbered parts.

MJ71-190 Underbody Assembly diagram

Exploded view of the MJ71-190 underbody assembly with numbered parts.

MJ71-190 Drivetrain and Roller Height Adjuster Assembly diagram

Exploded view of drivetrain and roller height adjuster assembly.

MJ71-190 Parts List

Detailed list of parts for the MJ71-190 with part numbers and quantities.

MJ71-240 Spare Parts

MJ71-240 General Assembly diagram

Exploded view of the MJ71-240 general assembly with numbered parts.

MJ71-240 Underbody Assembly diagram

Exploded view of the MJ71-240 underbody assembly with numbered parts.

MJ71-240 Drivetrain and Roller Height Adjuster Assembly diagram

Exploded view of drivetrain and roller height adjuster assembly.

MJ71-240 Parts List

Detailed list of parts for the MJ71-240 with part numbers and quantities.

MJ71-190FM Spare Parts

MJ71-190FM General Assembly diagram

Exploded view of the MJ71-190FM general assembly with numbered parts.

MJ71-190FM Parts List

Detailed list of parts for the MJ71-190FM with part numbers and quantities.

MJ71-240FM Spare Parts

MJ71-240FM General Assembly diagram

Exploded view of the MJ71-240FM general assembly with numbered parts.

MJ71-240FM Parts List

Detailed list of parts for the MJ71-240FM with part numbers and quantities.

MJ71 - Wheel Assembly

SW2-CW-01 Wheel Assembly diagram

Exploded view of the SW2-CW-01 wheel assembly.

MJ71 Spare Parts - MJ71-540/400/340

MJ71-540 Overview diagram

Exploded view of the MJ71-540 overview with numbered parts.

MJ71-400 Overview diagram

Exploded view of the MJ71-400 overview with numbered parts.

MJ71-340 Overview diagram

Exploded view of the MJ71-340 overview with numbered parts.

MJ71-340/400/540 Spare Parts

MJ71-340/400/540 Body diagram

Exploded view of the MJ71-340/400/540 body assembly with numbered parts.

MJ71-340/400/540 Body diagram

Exploded view of the MJ71-340/400/540 body assembly with numbered parts.

MJ71-340/400/540 Body diagram

Exploded view of the MJ71-340/400/540 body assembly with numbered parts.

MJ71-340/400/540 Body Parts List

Detailed list of parts for the MJ71-340/400/540 body.

MJ71-540 Spare Parts

MJ71-540 Wing diagram

Exploded view of the MJ71-540 wing assembly with numbered parts.

MJ71-540 Wing diagram

Exploded view of the MJ71-540 wing assembly with numbered parts.

MJ71-540 Wing Parts List

Detailed list of parts for the MJ71-540 wing.

MJ71-400/340 Spare Parts

MJ71-400/340 Wing diagram

Exploded view of the MJ71-400/340 wing assembly with numbered parts.

MJ71-400/340 Wing diagram

Exploded view of the MJ71-400/340 wing assembly with numbered parts.

MJ71-400/340 Wing Parts List

Detailed list of parts for the MJ71-400/340 wing.

MJ71-340 Spare Parts

MJ71-340 Wing diagram

Exploded view of the MJ71-340 wing assembly with numbered parts.

MJ71-340 Wing diagram

Exploded view of the MJ71-340 wing assembly with numbered parts.

MJ71-340 Wing Parts List

Detailed list of parts for the MJ71-340 wing.

MJ71-400FM Spare Parts

MJ71-400FM Overview diagram

Exploded view of the MJ71-400FM overview with numbered parts.

MJ71-400FM Body Assembly diagram

Exploded view of the MJ71-400FM body assembly with numbered parts.

MJ71-400FM Wing Assembly diagram

Exploded view of the MJ71-400FM wing assembly with numbered parts.

MJ71 Spare Parts - MJ71-730T/600T

MJ71-600T Overview diagram

Exploded view of the MJ71-600T overview with numbered parts.

MJ71-730T Overview diagram

Exploded view of the MJ71-730T overview with numbered parts.

MJ71-600T/730T Spare Parts

MJ71-600T/730T Body diagram

Exploded view of the MJ71-600T/730T body assembly with numbered parts.

MJ71-600T/730T Body diagram

Exploded view of the MJ71-600T/730T body assembly with numbered parts.

MJ71-600T/730T Body Parts List

Detailed list of parts for the MJ71-600T/730T body.

MJ71-600T Spare Parts

MJ71-600T Wing Parts List

Detailed list of parts for the MJ71-600T wing.

MJ71-730T Spare Parts

MJ71-730T Wing diagram

Exploded view of the MJ71-730T wing assembly with numbered parts.

MJ71-730T Wing Parts List

Detailed list of parts for the MJ71-730T wing.

MJ71 Blades

725-BLD7-FL Blade details

Exploded view and part list for 725-BLD7-FL blades.

725-BLD7-FR Blade details

Exploded view and part list for 725-BLD7-FR blades.

MJ71 Blades - Option 2

725-BLD4-FL Blade details

Exploded view and part list for 725-BLD4-FL blades.

725-BLD4-FR Blade details

Exploded view and part list for 725-BLD4-FR blades.

MJ71-600/730 Blades

725-BLD8-FL5 Blade details

Exploded view and part list for 725-BLD8-FL5 blades.

725-BLD8-FR5 Blade details

Exploded view and part list for 725-BLD8-FR5 blades.

MJ71-600T Wing - Parts List

MJ71-600T Wing Parts List

Detailed list of parts for the MJ71-600T wing.

MJ71-730T Wing - Parts List

MJ71-730T Wing Parts List

Detailed list of parts for the MJ71-730T wing.

MJ71-340T/400T/540T Trailed kit assembly

Trailed kit assembly diagram

Exploded view of the trailed kit assembly with numbered parts.

Trailed kit assembly diagram

Exploded view of the trailed kit assembly with numbered parts.

MJ71-600T/730T Trailed kit assembly

Trailed kit assembly diagram

Exploded view of the MJ71-600T/730T trailed kit assembly with numbered parts.

MJ71-340T/400T/540T Trailed kit assembly

Trailed kit assembly diagram

Exploded view of the MJ71-340T/400T/540T trailed kit assembly with numbered parts.

MJ71-600T/730T with brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-600T/730T braked models.

MJ71-340T/400T/540T with brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-340T/400T/540T braked models.

MJ71-340T/400T/540T without brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-340T/400T/540T non-braked models.

MJ71 Hydraulics

MJ71-340/400/540 (SW2-HYD01) hydraulic diagram

Diagram of the hydraulic system for MJ71-340/400/540 models.

MJ71-600T/730T with brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-600T/730T braked models.

MJ71-340T/400T/540T with brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-340T/400T/540T braked models.

MJ71-340T/400T/540T without brakes

Hydraulic system diagram

Diagram of the hydraulic system for MJ71-340T/400T/540T non-braked models.

Hydraulic Ram spares

Seal kits for hydraulic rams

Part numbers for seal kits for specific hydraulic rams.

MJ71 Rollers

Roller model identification

Table listing roller part numbers and corresponding machine models.

Roller End - Parts List

Exploded view and list of parts for the roller end assembly.

MJ71 Scraper Bars

Scraper bar part numbers and quantities

List of scraper bar assemblies and their quantities per model.

MJ71 PTO shafts

PTO shaft selection and safety

Table listing PTO shafts, compatible machines, and safety torque.

Axle Stub Components

50 SQ 5 Stud unbraked axle stub kit

Exploded view and parts list for unbraked axle stub hub.

50 SQ 5 Stud braked axle stub kit

Exploded view and parts list for braked axle stub hub.

LF205H-205 872-1.92 Gearbox

Gearbox assembly diagram and parts list

Exploded view and parts list for the LF205H-205 gearbox.

LF205TH-205.874-1.92 Gearbox

Gearbox assembly diagram and parts list

Exploded view and parts list for the LF205TH-205.874-1.92 gearbox.

MJ40T11-347.805-1 Gearbox

Gearbox assembly diagram and parts list

Exploded view and parts list for the MJ40T11-347.805-1 gearbox.

JJ.03499-1.9 (1:1.9 3 way gearbox)

Gearbox assembly diagram and parts list

Exploded view and parts list for the JJ.03499-1.9 gearbox.

TF26A-266.208-1.84 4W Gearbox

Gearbox assembly diagram and parts list

Exploded view and parts list for the TF26A-266.208-1.84 4W gearbox.

Website Registration

Register your machine for warranty

Instructions to register machine for warranty via the website.

Company Contact Information

Major Equipment Intl Ltd contact details

Contact information for Ireland, UK, and Netherlands/Germany offices.

Related product manuals
