Operator Manual
and Parts List
MAJOR
FINISHING MOWERS
MR150, MR180 and MR235

Table of Contents

Questions and Answers

  • B
    Beth BlankenshipAug 16, 2025
    Why does my Major MR150 leave a streak of uncut grass?
    • G
      greenmichaelAug 16, 2025
      Streaks of uncut grass can occur for several reasons. The blades might be dull or bent, requiring replacement. The carrier RPM could be too low, so ensure you're using the correct PTO speed. If field conditions are too wet, stop mowing and wait for drier conditions. A ground speed that is too fast can also cause this, so reduce your speed by shifting to a lower gear. If the grass is down due to weather, try mowing in only one direction. Lastly, there might be a build-up of materials under the mower, so clean the mower.
  • R
    Regina MathisAug 19, 2025
    Why is my Major MR150 Lawn Mower gearbox overheating?
    • C
      Carolyn TaylorSep 12, 2025
      An overheating gearbox can be caused by several factors: the lubricant level might be low, requiring you to fill it to the proper level; the lubricant type might be incorrect, so replace it with the proper lubricant; or there might be excessive trash build-up around the gearbox, which you should remove.
  • R
    Regina BishopAug 22, 2025
    What to do if material discharges from Major MR150 Lawn Mower unevenly?
    • B
      bobbyaliAug 22, 2025
      Uneven discharge can happen if the material is too high or there's too much of it. Reduce ground speed while maintaining 540rpm at the tractor PTO, or make two passes over the material, raising the mower for the first pass and lowering it to the desired height for the second, cutting at a 90-degree angle to the first pass. Also, if the grass is wet, allow it to dry before mowing, and slow down the tractor's ground speed while keeping the engine running at full PTO rpm.
  • J
    Javier RiceAug 25, 2025
    Why Major Lawn Mower seems to require excessive power?
    • A
      Ashley JonesAug 26, 2025
      If your mower requires excessive power, it could be due to several reasons. You might be advancing into the grass too rapidly, so reduce your forward travel speed. The mower might be hitting the ground, so raise it and reset the wheels. The blades might be worn or dull, in which case you should sharpen or replace them. Finally, the tractor might not be large enough, so consider using a larger horsepower tractor.
  • T
    tnguyenAug 27, 2025
    Why does my Major MR150 have excessive vibration?
    • M
      Melissa JohnsonAug 27, 2025
      Excessive vibration can stem from several issues. Start by checking the gearbox bolts and tightening them if they're loose. Also, check for loose nuts on the blades and tighten those as well. A broken blade can cause vibration, so replace the blades as a set. Avoid mixing new blades or bolts with worn ones; replace blades or bolts in sets. Finally, ensure the drivelines are phased correctly, with implement and tractor yokes in line, and replace if necessary.
  • A
    Abigail Olson MDAug 30, 2025
    What to do if Major Lawn Mower blade is scalping ground?
    • K
      Kenneth JonesAug 30, 2025
      If the blade is scalping the ground, it could be because the mower is set too low, so raise the mower and reset the wheels. Alternatively, if the field is ridged, try cutting it at a different angle. Also, if the field is too wet, stop mowing and wait until it has dried.
  • M
    Morgan Garcia DDSSep 1, 2025
    Why is my Major Lawn Mower gearbox noisy?
    • A
      Ashley HoweSep 2, 2025
      A noisy gearbox could be due to a worn bearing, which would need replacing. Another possibility is low oil in the gearbox, so check the level and add oil if needed.
  • J
    Joyce AllenSep 4, 2025
    What to do if Major Lawn Mower will not cut?
    • B
      Brenda ChavezSep 5, 2025
      If your mower won't cut, and it's a shear bolt drive model, the shear bolt may have sheared, requiring you to install a new one. Alternatively, the belts might have slipped and need stretching, or the belts may be broken and need replacement.
  • R
    reidjoySep 7, 2025
    Why Major MR150 Lawn Mower blades wear too fast?
    • C
      Caitlin WoodwardSep 7, 2025
      Blades wearing out quickly can be due to several reasons. You might be cutting in sandy or rocky conditions, so increase the cutting height. Also, blades hitting the ground can cause excessive wear, so increase the cutting height.
  • D
    Dominic WilsonSep 10, 2025
    What to do if Major MR150 PTO contacts mower front frame when raised?
    • A
      angelaoliverSep 10, 2025
      If the PTO contacts the mower's front frame when raised, it's likely due to raising the mower too high or incorrect adjustment of the tractor top link. Adjust the top link or tractor lift stops according to the attachments instructions.

Summary

Introduction

Identification Data and Main Parts

Key to the Main Parts

Identifies and labels key components of the mower.

General Safety Regulations

Driveline Safety Regulations

Outlines essential safety rules for operating the driveline.

Starting Regulations

General Operation Guidelines

Transit on Public Highways

Maintenance Technician Instructions

Test Regulations

Warning Danger Plates and Stickers

Sticker Numbers and Locations

Key to Safety Devices

Explains the function of various safety components on the mower.

Noise and Vibrations

Disclaimer

Delivery and Handling

Assembling the Mower & Hitching to Tractor

Assembling the Mower - Rear Discharge Unit

Detailed instructions for assembling the rear discharge configuration.

Assembling the Mower - Side Discharge Unit

Transforming Rear to Side Discharge

Transforming Side to Rear Discharge

Hitching the Mower to the Tractor

PTO Shaft Length Adjustment

Operation and Use of the Mower

Driving on Roads

Rules for safe transportation of the mower on public roads.

Preparing the Mower for Work

Pre-work checks and adjustments for the mower.

Adjusting the Cutting Height

Using the Mower

Demounting the Implement

Maintenance of the Mower

Factory Checks and Inspections

Pre-delivery inspections performed by the manufacturer.

Inspection Before Use

Daily checks to ensure the mower is safe and ready for operation.

Periodic Maintenance Inspections

Scheduled maintenance tasks based on operating hours.

8-Hour Service Intervals

Lubrication and checks required every 8 hours of operation.

50-Hour Service Intervals

Checks and maintenance required every 50 hours of operation.

250-Hour Service Intervals

Major service tasks required every 250 hours of operation.

Gearbox Oil and Belt Tension

Blade Replacement and Checks

Machine Cleaning and Lubrication

Long-Term Storage and Disposal

Frame Kit - MR150 & MR180 Parts

Transmission Rotors - MR150 & MR180 Parts

Rear Discharge Parts - MR150 & MR180

Side Discharge Parts - MR150 & MR180

Gearbox Parts - MR150, MR180 & MR235

Mulching Version Parts - MR150 & MR180

Frame Kit - MR235 Parts

Transmission Rotors - MR235 Parts

Grease Extensions - MR235 Parts

Anti-Scalping Roller - MR235 Parts

Troubleshooting Common Issues

Warranty Procedure

Major MR150 Specifications

General IconGeneral
BrandMajor
ModelMR150
CategoryLawn Mower
LanguageEnglish
