MAJOR RANGE OF
TDR ROLLERMOWERS
TDR 16000
TDR 20000
Operator Manual
& Parts List

Table of Contents

Questions and Answers

  • M
    Michael WilsonAug 16, 2025
    What to do if Major TDR Lawn Mower discharges material unevenly?
    • V
      vlynnAug 16, 2025
      If your Major Lawn Mower discharges material unevenly, leaving bunches along the swath, it could be due to a couple of reasons. First, the material might be too high and too much. To resolve this, reduce your ground speed while maintaining 540rpm at the tractor PTO, or make two passes over the material, raising the mower for the first pass and lowering it to the desired height for the second, cutting at a 90-degree angle to the first pass. Also, if the grass is wet, allow it to dry before mowing and slow down the ground speed of the tractor while keeping the engine running at full PTO rpm. Cutting lower may also help.
  • B
    Brian ScottAug 19, 2025
    What to do if Major Lawn Mower blade is scalping ground?
    • B
      Briana MyersAug 19, 2025
      If your Major Lawn Mower blade is scalping the ground, it could be because the mower is set too low, so raise the mower and reset the wheels. Alternatively, the field may be ridged, in which case you should cut the field at a different angle. If the field is too wet, stop and wait until it has dried.
  • J
    joanneturnerAug 22, 2025
    Why Major TDR Lawn Mower leaves a streak of uncut grass?
    • V
      vedwardsAug 22, 2025
      If your Major Lawn Mower leaves a streak of uncut or partially cut grass, several factors could be at play. The blades might be dull or bent, requiring replacement. The carrier RPM could be too low, so ensure you're using the correct PTO speed. If the field conditions are too wet, it's best to halt operation until it dries out. A ground speed that's too fast can also cause this issue, so reduce it by shifting to a lower gear. If the grass is down from previous weather, try mowing in only one direction. Also, check for any build-up of materials under the mower and clean it if necessary. Finally, ensure the blades are mounted correctly, with the cutting edge facing the correct rotation.
  • T
    thomasjasonAug 25, 2025
    How to fix excessive vibration in Major TDR Lawn Mower?
    • T
      Teresa NielsenAug 26, 2025
      If your Major Lawn Mower is experiencing excessive vibration, there are several things you can check: * Tighten any loose gearbox bolts. * Tighten any loose nuts on the blades. * Replace any broken blades in a set. * Ensure that new blades or bolts are not mixed with worn ones; replace blades or bolts in sets. * Phase the driveline, ensuring the implement and tractor yokes are in line, and replace if necessary.
  • S
    Shane McdonaldAug 27, 2025
    Why is the gearbox overheating on my Major TDR?
    • A
      Anthony GriffinAug 28, 2025
      If the gearbox of your Major Lawn Mower is overheating, it could be due to several reasons. First, check the lubricant level and fill it to the proper level if it's low. If the lubricant is the improper type, replace it with the correct one. Also, remove any excessive grass or debris build-up around the gearbox.
  • A
    Alex RollinsAug 30, 2025
    Why is my Major Lawn Mower so noisy?
    • B
      Brittany MitchellAug 30, 2025
      If your Major Lawn Mower is making excessive noise, several factors could be the cause. Check for worn bearings and replace them if necessary. Ensure the oil level in the gearbox is adequate and add oil if it's low. Inspect for any loose parts and fully tighten all bolts. Verify that the PTO RPM rate is correct and adjust as needed. Replace any bent or missing blades. Check that the PTO shafts are aligned correctly. Also, check the output shaft on gearboxes and the driveline between gearboxes are aligned.
  • C
    Cathy BrownSep 3, 2025
    Why do blades wear too fast on Major TDR Lawn Mower?
    • M
      Miss Jacqueline SuttonSep 3, 2025
      If the blades of your Major Lawn Mower are wearing too fast, it might be because you are cutting in sandy or rocky conditions, or the blades are hitting the ground. To resolve this, increase the cutting height.
  • B
    Barbara CarneySep 5, 2025
    Why is the gearbox leaking on my Major TDR Lawn Mower?
    • J
      joan19Sep 6, 2025
      If the gearbox on your Major Lawn Mower is leaking, there are several potential causes. It could be due to a damaged oil seal, a bent shaft, or a shaft that is rough in the oil seal area. The oil seal might also be installed incorrectly or not sealing in the housing. Other possible causes include an oil level that is too high, a hole in the gearbox, a damaged gasket, or loose bolts. To address these issues, you may need to replace the seal, shaft, or gasket, use a sealant on the outside diameter of the seal, drain oil to the proper level, replace the gearbox, or tighten the bolts.
  • M
    Melissa HernandezSep 8, 2025
    Why does my Major TDR require excessive power?
    • B
      becklisaSep 8, 2025
      If your Major Lawn Mower seems to require excessive power, it could be due to several reasons. You might be advancing into the grass too rapidly, in which case you should reduce your forward travel speed. The mower might be hitting the ground, so raise the mower and reset the wheels. The blades could be worn or dull, so sharpen or replace them. Finally, the tractor might not be large enough, so use a larger horsepower tractor.
  • W
    Walter DicksonSep 12, 2025
    What to do if Major Lawn Mower will not cut?
    • E
      ereillySep 12, 2025
      If your Major Lawn Mower will not cut, it is possible that the shear bolt sheared. Install a new shear bolt to resolve this.

Summary

Safety Features

Safety Labels Overview

Operational Hazard Identification

Specific Machine Hazards

Details hazards like cutting, pinching, entanglement, projectiles, run-on, hydraulics, and slips.

Noise and Safe Operation Practices

Safe Operating Procedures

Covers essential safety precautions, protective gear, and workstation requirements.

PTO Shaft and Road Safety

PTO Shaft Safety Precautions

Essential safety measures for operating and maintaining PTO shafts.

Operating the Machine: Initial Steps

Pre-Operation Inspections

Detailed checks before use, including oil levels, greasing, and blade security.

Machine Components and Setup

Starting and Hitching Procedures

Covers starting regulations and safe tractor hitching.

Operational Warnings and Controls

Critical Operational Warnings

Remote Control System

Maintenance and Troubleshooting

Routine Maintenance Tasks

Adjusting rollers, blade rotations, PTO shaft, belts, and taper bushes.

Troubleshooting Common Issues

Solutions for faults like uneven cutting, gearbox issues, and blade wear.

Hydraulic System Details

Hydraulic Valve Bank

Blade System Information

Blade System Types

Blade Rotations and Timing

PTO Shafts and Gearboxes

PTO Shaft Specifications

Gearbox Identification

Major TDR Series Specifications
