MAJORITY SCH-DVD-BLK - DVD Player Panel Layout; Front Panel Components; Rear Panel Components

27 pages

To Next Page

To Previous Page

Controls And Funcons

Rear Panel

Front Panel

OPEN/CLOSE

USB

PLAY/PAUSE STOP

POWER

1 2 3

4 5 6 7 8

9. (Y.Pb/Cb.Pr/Cr) Output

10. Power Cable Outlet

11. HDMI Output

12. 2 x Audio Output ports

13. Video Output

1. DVD Tray

2. Remote Sensor

3. Display

4. USB Port

5. Open/Close

6. Play/Pause

7. Stop

8. Power On/O

MODEL:SCH-DVD-BLK

POWER SOURCE:100-240V ~ 50/60HZ

POWER CONSUMPTION:≤15W

11 12 13

9 10
