Cylinder Head
Repair / Reassembly
A5.05. 01.11.01.00
M20
en / 30.09.2010 IB001353 1/5
01
See also: 01.01.01.nn, 01.02.01.nn, 01.06.01.nn, 02.06.01.nn, 07.07.01.nn
Spare parts list: B1.05.01.2.2107
Time requirement: 1 Pers./ 1,00 h
Personnel qualification: skilled engine hand
--------------------------------------------------------------------------------------------------------------------------------
Operating medium: Heavy fuel and distillate fuel
Tools:
See maintenance sheet 01.06.01.nn.
Auxiliary material:
High-temperature thread paste “Dag S-5080” *
Molykote paste “G-Rapid Plus” *
Vaseline *
* or a product of equal standard
NOTE
When lifting the cylinder head or when turning afterwards, the cylinder liner is always
to be secured with the hold-down to prevent the liner from coming loose.
CAUTION
Do not fall below minimum bending radius r = 120 mm of the high-pressure hoses.
Only use hydraulic oil as an operating material.
DANGER
No parts of the body should be over the equipment which is under pressure.
