Exhaust Manifold
Maintenance / Disassembly and reassembly
A5.05. 06.01.01.00
30000, 7500
M20
en / 31.05.2010 IB022083 1/2
06
See also:
Spare parts list: B1.05.06.2.72n0
Time requirement: 1 Pers./ 3,00 h
Personnel qualification: skilled engine hand
--------------------------------------------------------------------------------------------------------------------------------
Operating medium: Heavy fuel and distillate fuel
Inspection:
Exhaust manifolds must be examined for leakages after 7,500 h
Maintenance:
Remove and clean exhaust manifold after 30,000 h
Auxiliary material:
High temperature-thread paste “Dag S-5080” *
* or a product of equal standard
Sequence of operations:
1. Inspection
1.1 Remove the covering from the exhaust manifold.
1.2 Check all bolts for tightness.
1.3 Carry out a visual inspection at the flanged connections and expansion joints (inspection must be
carried out with the engine running).
NOTE
Check also the exhaust piping after the turbocharger when doing the work on the ex-
haust manifold.
If excessive vibrations and noises occur in the exhaust-gas turbine, the flanged con-
nection on the exhaust pipe behind the turbine must be unscrewed and examined for
pipe tension.
To safeguard the expansion joints these must not be subjected to bending or radial
forces on removal and fitting. A small preload (expansion), however, is necessary in
axial direction when installing (about 3mm).
Fit all screws with high temperature-thread paste “Dag S-5080” to avoid sticking due
to heat.
