Control shaft bedding
Maintenance / Checking
A5.05. 05.01.02.00
1500
M20
en / 10.12.2010 IB026480 1/1
05
See also: -
Spare parts list: B1.05.04.2.4110, B1.05.05.2.4210, B1.05.05.2.4521, B1.05.05.2.4523
Time requirement: 1 Pers./ 0,20 h
Personnel qualification: skilled engine hand
--------------------------------------------------------------------------------------------------------------------------------
Operating medium: Heavy fuel and distillate fuel
Maintenance:
Oil control shaft after 1.500 h
Auxiliary material:
Multi-purpose grease or lubricating oil according to A4.05.08.nn
Sequence of operations:
1. Remove control shaft/injection pumps and control station covers.
2. Check control shaft and spindle to emergency-off lever and oil bearing areas slightly with lubrica-
ting oil.
3. Oil all moving bearings of the following components slightly:
- swivel head of spring link between control shaft and regulator
- swivel arm between control shaft and injection pump
- dual pivoting bearing of clutch between control station and control shaft
4. Assemble covers.
CAUTION
After cleaning with fat dissolving agents, all bright-metallic components are to be oiled
slightly.
Care has to be taken that all cleaned bearings are thoroughly greased.
