MAK M 20 - Page 180

Vibration damper on camshaft
Repair / Disassembly and reassembly
A5.05. 04.09.01.00
15000
M20
en / 31.05.2010 IB021594 2/2
04
2.3 Assemble the cover disc (3), the damper
(1), sleeves (6) and
cheese head screws (5) according to the
illustration.
2.4 Tighten the cheese head screws (5) with a
torque of
M = 60 Nm.
