Exhaust Manifold
Maintenance / Disassembly and reassembly
A5.05. 06.01.01.01
7500
M20
en / 30.09.2010 IB025358 1/3
06
See also:
Spare parts list: B1.05.06.2.72n0
Time requirement: 1 Pers./ 3,00 h
Personnel qualification: skilled engine hand
--------------------------------------------------------------------------------------------------------------------------------
Operating medium: Heavy fuel and distillate fuel
Checks:
Check exhaust pipe for leaks after 7,500 hrs
Auxiliary material:
High temperature bolt lubricant "Rivolta G.W.F“ *
* or comparable product
Procedure:
1. Remove exhaust pipe sheathing.
2. Check tightness of all bolt connections.
NOTE
In order to prevent longitudinal strain of the expansion joints, they should not be sub-
jected to bending and/or radial forces during disassembly and assembly.
However, for the expansion joint ahead of the turbine, a slight preload in axial direc-
tion (strain) is required during installation.
Coat all bolts with high temperature bolt lubricant "Rivolta G.W.F." before installation
in order to protect them from seizure.
DANGER
Caution, hot engine components can cause burns!
Always check temperatures before beginning work on exhaust pipes! Let exhaust
piping cool sufficiently!
