Charge Air Cooler
Maintenance / Disassembly and reassembly
A5.05. 06.04.02.01
M20
en / 31.05.2010 IB002304 2/2
06
2. Reassembly
2.1 Carry out reassembly in reverse order to disassembly.
2.2 Renew all seals.
2.3 Lubricate hexagon screws (Fig. 1/2) with Molykote paste “G-Rapid Plus” and tighten with a torque
of
M = 60 Nm.
WARNING
Observe regulations of the manufacturer for cleansing agent to be used, protect skin
against contact with cleansing agent, wear safety glasses. Ensure good ventilation.
NOTE
Ensure proper fit of the sealing plates in the housing.
