Charge Air Cooler
Maintenance / Disassembly and reassembly
A5.05. 06.04.02.02
M20
en / 31.05.2010 IB004328 2/2
06
2. Reassembly
2.1 Renew all gaskets
2.2 Grease hexagon screws (1,2 and 3) with Molykote paste „G-Rapid Plus“.
2.3 Secure charge air cooler on hoist and push cooler into casing
Strictly observe the tightening instructions for hexagon screws (1, 2 and 3).
2.4 Mount hexagon screws (1 and 3) and slightly tighten them crosswise to provide for uniform
contact of the charge air cooler on front and sides.
2.5 Tighten hexagon screws (1) crosswise in small steps up to a torque of
M = 60 Nm.
2.6 Tighten hexagon screws (3) crosswise in small steps up to a torque of
M = 60 Nm.
2.7 Mount hexagon screws (2) and tightem them crosswise in small steps up to a torque of
M = 60 Nm.
