Fuel Injector
Maintenance / Disassembly and reassembly
A5.05. 07.07.01.02
M20
en / 30.09.2010 IB026440 3/3
07
2.6 Tighteen the thrust bolts (1 and 2) manually in alternating order, becauce of tapered seat of the
transverse thrust piece (3) on the injection pump.
2.7 First tighten thrust bolt (2) and then thrust bolt (1) with a torque of
M = 85 Nm.
2.8 Tighten nuts ( Fig. 3/15) once again with a torque of
M = 30 Nm.
