TEMPI Panel Controls
1. Channel 1 Output
2. Channel 2 Output
3. Channel 3 Output
4. Channel 4 Output
5. Channel 5 Output
6. Channel 6 Output
7. State Select Gate Input
8. State Select CV Input
9. Select CV Attenuator/Combo Pot
10. External Leading Tempo Input
11. Tempo LED
12. PGM_A Button / LED
5
7
8
14
13
1
6
16
3
10
21
20
2
9
12
19
18
4
15
17
13. PGM_B Button/ LED
14. Channel Button-1 / LED
15. Channel Button-2 / LED
16. Channel Button-3 / LED
17. Channel Button-4 / LED
18. Channel Button-5 / LED
19. Channel Button-6 / LED
20. State LED
21. Mod Gate Input
22. Mod LED
11
22
PAN EL ConTRoLS
