Headless Set Screw M3×5
Wr ench
Nut M4
Hex Allen K ey 1.5mm
1. Tools
2. Make sure to tighten the screw and the nut.
Please assemble the robot in strict accordance with the following three requirements, otherwise it will result in inaccuracy or unsatisfying performance.
Basic Knowledge -- Assembly Requirement
10 11
Tighten the screw with force according
to the direction of the diagram
Tighten the screw with force according
to the direction of the diagram
Screw M3×8 Screw M4
