7 ENGLISH
PARTS DESCRIPTION
18
1
2
3 4
98
6
5
7
10
11
12
14
15
17
13
16
19
20
1 Abrasivecut-o󰀨wheel/
diamond wheel
2 Wheel guard 3 Grip 4 Cover(forbattery
compartment)
5 Lock-o󰀨button 6 Hook 7 Lamp 8 Check button
9 Batteryindicator 10 Overload indicator 11 Lamp button 12 Switch trigger
13 Handle 14 Water inlet 15 Cock 16 Cover(forV-belt)
17 Shaft lock button 18 Coupling sleeve 19 Box wrench 20 Hex wrench
