13 ENGLISH
1
2
4
3
►1. Lock-off button 2. Locking lever 3. Lock pin
4. Hole for lock pin
2. Press the shaft lock fully so that the blade cannot
revolve and use the hex wrench to loosen the hex bolt.
2
1
3
4
►1. Shaft lock 2. Hex wrench 3.Tighten4. Loosen
3. Removethehexbolt,outerange,andcircular
saw blade.
4
3
2
1
►1. Hex bolt 2.Outerange3.Innerange
4. Circular saw blade
WARNING: If the inner ange is removed, be
sure to install it on the spindle. When installing,
choose a correct side on which protrusion ts
into the saw blade hole perfectly. Mounting the
blade on the wrong side can result in the dangerous
vibration.
Toinstallthecircularsawblade,followtheremoval
procedure in reverse. Depress the lock-off button to
release the lock pin from the hole.
WARNING: BE SURE TO TIGHTEN THE HEX
BOLT SECURELY. Also be careful not to tighten
the bolt forcibly. Slipping your hand from the hex
wrench can cause a personal injury.
Blade guard cleaning
When changing the circular saw blade, make sure to
also clean the blade guard of accumulated sawdust as
discussed in the Maintenance section. Such efforts do
not replace the need to check guard operation before
each use.

Makita DSP600 Specifications

General

Blade Diameter	165 mm
Max Cutting Capacity at 45°	40 mm
No Load Speed	2, 500 - 6, 300 RPM
Voltage	18V
Power Source	Battery
Max Cutting Capacity at 0°	56 mm
Max Cutting Capacity at 48°	38 mm
Bevel Capacity	48°
