Denomination of components
Indicate when ordering spare parts!
Identication plate
Serial no.
Year of manufacture
1 Handle
2 Filter cover
3 Filter hood clip
4 Tubular handle
5 Hand guard (release for chain brake)
6 Mufer with spark arrester screen
7 Spike bar
(toothed stop for holding saw steady against wood)
8 Chain tensioning screw
9 Retaining nuts
10 Chain catch
11 Sprocket guard
12 Adjusting screw for oil pump (bottom side)
13 Adjusting screws for carburetor
14 Identication plate
15 Starter grip
16
Combination switch (Choke / Start / Stop)
17 Throttle lever
18 Safety locking button
19 Rear hand guard
20 Fuel tank cap
21 Fan housing with starting assembly
22 Oil tank cap
23 Guide bar
24 Chain (Blade)
EA5000P
18 inch (45 cm) 2012.11 123456
chain bar
3/8” 513.496.664 443.045.661
.325” 513.486.672 445.045.641
XXX.XXX.XXX Typ 181
Makita Corporation, Anjo, Aichi, Japan
Made in Germany
