Makita ELM3320 User Manual

12 ENGLISH
5. Open the levers, and then place the cord over the
lever.
1
2
►1. Lever 2. Cord
6. Return the levers to the halfway position as shown
inthegure.
1
►1. Lever
7. Fold the handle.
1
►1. Handle
8. Placethemachineasshowninthegure.
CAUTION: Be sure to store this machine
indoors and place it on a at surface. Otherwise,
themachinemayfallandcauseaninjury.
You can also store the machine as follows.
1. Disconnect the extension cord.
1
►1. Extension cord
2. Open the rear cover, and then remove the grass
basket.
2
1
►1. Rear cover 2. Grass basket

Makita ELM3320 Specifications

General

Type	Walk behind lawn mower
Easy to use	Yes
Cutting width	33 mm
Grass catcher	No
Product color	Black, Turquoise
Maximum lawn area	400 m²
Mulching function	-
Handle(s) features	Adjustable
Maximum cutting height	55 mm
Minimum cutting height	20 mm
Number of height positions	3
Power source	AC

Weight and Dimensions

Depth	1230 mm
Width	380 mm
Height	1110 mm
