10 ENGLISH
Insert the bit into the tool. Turn the bit and push it in until it engages.
If the bit cannot be pushed in, remove the bit. Pull the
release cover down a couple of times. Then insert the
bit again. Turn the bit and push it in until it engages.
Afterinstallingthebit,alwaysmakesurethatthebitis
securelyheldinplacebytryingtopullitout.
1 2
►1. Bit 2. Release cover
To remove the bit, pull the release cover down all the
wayandpullthebitout.
2
1
►1. Bit 2. Release cover
Bit angle
Thebitcanbesecuredat12di󰀨erentangles.Tochange
the bit angle, slide the change ring cover forward, then
turn the change ring cover to change the bit angle. At the
desired angle, slide the change ring cover back to the
original position. The bit will be secured in place.
After changing the bit angle, make sure the angle is
xedbytryingtorotatethebit.
1
►1. Change ring cover
Dust extractor attachment
Optional accessory
1. Installthehoseholder(A).
Loosen the clamp nut, and then remove the hex bolt.
Installthehoseholder(A)betweenthehexboltandthe
clampnutbytighteningtheclampnutrmly.
1
2
3
►1. Hex bolt 2.Hoseholder(A)3. Clamp nut
2. Attachtheholderjointtothetool,andthenattach
thehoseholder(C)totheholderjoint.
1
2
►1.Holderjoint2.Hoseholder(C)
NOTE:Thehosejointcanbeattachedtoeitherside
of the tool.
WARNING: Use the mounting part of the tool
only for attaching the holder joint.
Usingthemountingpartforanyotherpurposemay
cause an unexpected accident.
