Makita HP332D User Manual

7 ENGLISH
Position of
speed
change lever
Speed Torque Applicable
operation
1 Low High Heavy load-
ing operation
2 High Low Light loading
operation
Tochangethespeed,switchoffthetoolrst.Select
the"2"sideforhighspeedor"1"forlowspeedbuthigh
torque.Besurethatthespeedchangeleverissettothe
correct position before operation.
If the tool speed is coming down extremely during the
operationwith"2",slidethelevertothe"1"andrestart
the operation.
Selecting the action mode
CAUTION: Always set the ring correctly to
your desired mode mark. If you operate the tool
with the ring positioned halfway between the
mode marks, the tool may be damaged.
CAUTION: When you change the position
from " " to other modes, it may be a little dif-
culty to slide the action mode changing ring. In
this case, switch on and run the tool for a second
at the " " position, then stop the tool and slide
the ring to your desired position.
1
2
3
4
►1.Actionmodechangingring2.Adjustingring
3. Graduation 4.Arrow
Thistoolhasthreeactionmodes.
•
Drilling mode (rotation only)
•
Hammer drilling mode (rotation with
hammering)
•
Screwdriving mode (rotation with clutch)
Selectonemodesuitableforyourwork.Turnthe
action mode changing ring and align the mark that you
selected with the arrow on the tool body.
Adjusting the fastening torque
1
2
3
4
►1.Actionmodechangingring2.Adjustingring
3. Graduation 4.Arrow
Thefasteningtorquecanbeadjustedin20stepsbyturningtheadjustingring.Alignthegraduationswiththearrow
onthetoolbody.Youcangettheminimumfasteningtorqueat1andmaximumtorqueat20.
Before actual operation, drive a trial screw into your material or a piece of duplicate material to determine which
torquelevelisrequiredforaparticularapplication.Thefollowingshowstheroughguideoftherelationshipbetween
the screw size and graduation.
Graduation 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20
Machine screw M4 M5 M6
Wood
screw
Soft wood
(e.g. pine)
– ɸ3.5 x 22 ɸ4.1x 38 –
Hard wood
(e.g. lauan)
– ɸ3.5 x 22 ɸ4.1x 38 –

Makita HP332D Specifications

General

Number of gears	2
Torque settings	21
Chuck capacity (min)	1 mm
Sound pressure level	82 dB
Idle speed (1st gear)	450 RPM
Idle speed (2nd gear)	6750 RPM
Impact rate (low speed)	1500 bpm
Sound level uncertainty	3 dB
Impact rate (high speed)	22500 bpm
Drilling diameter in wood (max)	28 mm
Vibration level (metal drilling)	2.5 m/s²
Maximum torque (hard applications)	35 N⋅m
Maximum torque (soft applications)	21 N⋅m
Drilling diameter in concrete (max)	10 mm
Vibration level (concrete drilling)	12.5 m/s²
Soft grip	Yes
Product design	Pistol grip drill
Product color	Black, Blue
Uncertainty K	1.5 m/s²
Number of batteries included	2 pc(s)
Power source	Battery
Battery voltage	10.8 V
Battery capacity	4 Ah

Weight and Dimensions

Depth	168 mm
Width	66 mm
Height	236 mm
Weight	1300 g
