Repair
P 3 / 26
Item No. Parts description
Blade case
Arm complete
Front arm complete
Apply 6g to the gear room if the room has been washed for cleaning.
Both pivot portions where front arm (item No. 145) contacts
Inside of hole which accepts arm holder's (156) rib portion.
Linear ball bearing in which pipe portion of front arm (145) slides
Surface to which inner wall of arm holder (156) contacts
Whole
16
136
139
145
O ring 5153
Pipe ends to which axis holes of front arm complete (145) contact
Swivel portion where arm complete (136) contacts
Pipe 16-90155
Arm holder156
Screw M10
Flat washer 10
Threads
Surfaces where thrust needle gauge 1024 (160) contacts
Head and reverse side to which washers 10 (159 and 161) contact
158
Thrust needle gauge 1024 160
159, 161
Stopper plate
Portion to lubricate
Pivot portion where blade case (16) contacts
WARNING: Be sure to unplug the tool before maintenance or repair.
See the instruction manual on how to handle the tool.
Remove the following parts from the machine for safety before repair/ maintenance:
*Saw Blade *Inner Flange *Outer Flange *Dust Nozzle
Linear ball bearing, factory-assembled
Helical gear 47
Stopper pin
Fig. 1
1. Apply Makita grease N. No.1 to the following portions designated by black triangle to protect parts and product from
unusual abrasion. See Fig. 1.
[1] Lubrication
