Makita LS0714L Technical Information

2. Apply Makita grease N. No.1 to the following portions designated by black triangle to protect parts and product from
unusual abrasion. See Fig. 2.
Item No. Parts item Portion to lubricate
17
Spiral spring 26 Whole
21 Center plate Portion where center cover contacts
27
Link plate
173
194
Turn base
Base
190
Grip 32
The boss for accepting (173) turn base's axis
Tip round portion
Axis
Threads
Linear ball bearing in which arm holder's (156) pipe slides
195, 196
Slide plate The surface on which (173) turn base's edge slides
Fig. 2
Factory-assembled
linear ball bearing
Axis of turn base
Center cover
Boss for accepting
the turn base's axis
Repair
P 4 / 26
