Maktec MT902 - Operation and Maintenance; Grinding and Sanding Operation; Wire Brush Operations; Abrasive Cut-Off;Diamond Wheel Operation

Wiring diagram
Wiring in Handle set (L)
P 9/ 9
Wiring in Motor housing on the Commutator side
Pass Field lead wires
through hooks.
Hooks
To be connected
to Switch
Field lead wires (black)
Switch
Noise Suppressor
Power supply cord
Pass the Lead wires of Power
supply cord between Ribs.
Put Noise suppressor
here if it is used.
Fix Field lead wires
(2 x black) with Lead
wire holder.
Field lead wires
(black)
Rib
Handle Set (L)
Fig. D-2
Fig. D-3
