ELECTRIC SYSTEM TROUBLESHOOTING
ENGLISH
SECTION 2
Electrical Components
SECTION 2
B - TROUBLESHOOTING
1
2
3
4
5
6
7
8
910111213
14
15
16
17
KEY TO ELECTRICAL COMPONENTS
1) FRONT STOP SWITCH
2) REGULATOR
3) CONTROL UNIT
4) 10 A FUSE
5) BATTERY
6) FLASHLIGHT
7) SIDE STAND SWITCH
8) COIL
9) REAR STOP SWITCH
10) MIXER OIL PROBE
11) SOLENOID
12) FUEL PROBE
13) H
2
O TEMPERATURE SENSOR
14) HORN
15) DIGITAL INSTRUMENT BOARD
16) KEY SWITCH
17) AIR TEMPERATURE SENSOR
