Mallory HYFIRE IVC - Page 8

8
MALLORY 8MM SUPPRE
GM/DELCO HEI DISTRIBUTOR
(WITH COIL MOUNTED INSIDE DISTRIBUTOR CAP)
ADAPTER / HARNESS
PART NOS. 29040 AND 29043
GM/DELCO HEI DISTRIBUTOR
(WITH REMOTE COIL ADAPTER)
ADAPTER / HARNESS
PART NOS. 29040 AND 29043
+
-
MALLORY
PROMASTER®
COIL
Part No. XXXXX
MALLORY 8MM SUPPRE
ABCD
ORANGE
GREEN
WHITE
PICKUP PLUG
CABLE TIE
YELLOW
CABLE TIE
IGNITION
CONTROL
PLUG
IGNITION
CONTROL
HARNESS
LONG BLACK
(–) BATTERY (+)
LONG RED
SMALL RED / MAG +
PINK OR RED
NOTE: LEAVE TACH PLUG, IF THERE IS ONE,
PLUGGED INTO THE DISTRIBUTOR CAP
YELLOW
BLACKBROWN
TO VEHICLE
HARNESS
SMALL
GREEN
SMALL
BLACK
SMALL BLACK / MAG –
SMALL RED / MAG +
ADAPTER / HARNESS
PART NO. 29040
SMALL
GREEN
SMALL
BLACK
YELLOW
GREEN NOT USED
BLACK
SMALL BLACK / MAG –
RED
BAT
PLUG
GREEN
NOT USED
CHASSIS/FRAME GROUND
(DO NOT CONNECT TO
ENGINE BLOCK)
HYFIRE
®
IGNITION
SYSTEM
®
IGNITION
CONTROL
PLUG
IGNITION
CONTROL
HARNESS
LONG BLACK
(–) BATTERY (+)
LONG RED
TO VEHICLE
HARNESS
GM/DELCO HEI DISTRIBUTOR
WITH MALLORY HEI REMOTE
COIL ADAPTER INSTALLED
BAT
PLUG
CHASSIS/FRAME GROUND
(DO NOT CONNECT TO
ENGINE BLOCK)
NOTE: DO NOT USE IGNITION BALLAST
RESISTORS SUPPLIED WITH
PROMASTER® COILS OR OTHER
AFTERMARKET COILS.
TACHOMETER / RPM SENSING LEAD:
CONNECT THE TACH LEAD TO THE
COIL (–) TERMINAL.
HYFIRE
®
IGNITION
SYSTEM
®
ADAPTER / HARNESS
PART NO. 29040
ADAPTER / HARNESS
PART NO. 29043; 2 OF 2
ADAPTER / HARNESS
PART NO. 29043; 1 OF 2
GM/DELCO HEI DISTRIBUTOR
WITH COIL MOUNTED INSIDE
DISTRIBUTOR CAP
MAGNETIC
PICK-UP WIRES
NOTE: DISCARD ADAPTER / HARNESS PART
NO. 29043 WITH YELLOW AND BROWN WIRES.
SPADE RECEPTACLE TERMINALS
SPADE RECEPTACLE TERMINALS
FIGURE 11
FIGURE 12
