Note: max weight is 4.1kg, the wall should be able to carry this weight.
PTC-3007L-E PTC-3013L-E
PTC-3014L-E
PTC-3015L-E 、PTC-3016L-
E
PTC-3017L-E、PTC-3018L-E
PTC-3019L-E、PTC-3020L-E
PTC-3015L-EA
1、The distance between the product and the ceiling(and the
side) should be ≥30cm.
2、Product installation size see Figure.
3、Note: when the product is installed, The hook (screw) is
aligned with the hole "A" on the product. After hanging, must be
moved to the "B", in order to firmly fix.
When to remove the product, must be moved from "B" to "A"
then take out.
Technical parameters:
Model Rated Power
Rated
Voltage
Rated
Frequency
Class II
PT3800Wt DISPLAY +
pilot 2000W 220-240V~ 50-60Hz
Usage:
1. Please make sure the capacity should be 220-240V~, 50-60Hz.
2. Put the plug in the wall socket.
3. Switch the appliance on by selecting the desired setting.
“0” is “OFF”. “I”: is “ON”.
4. Please operate the machine according the control keys on the control panel or
the infrared controller. （you can see the control panel and infrared controller in
this paper）
16/38
