AIR COMPRESSOR OPERATING INSTRUCTIONS:
CAUTIONS
Do not operate the Air Compressor more than 15 Minutes continuously. Allow the
compressor to cool down for 10 minutes between each continuous operation.
Review the products to be inflated for manufacturer’s recommended maximum inflation
pressure. Most tires are recommended to be inflated between 27 to 38 PSI.
Always check the air inflation pressure with a separate and reliable pressure gauge during
and after inflation.
A. TO INFLATE TIRES:
IMPORTANT: Turn the Main Booster Power Switch to ON position. The LED indicator located
in the front panel will illuminate BLUE indicating power is available in the Boost 200 system.
1. Open the Compressor Air Hose Compartment access door at the left side of the Boost 200 and pull
out the air hose. Make sure that the Nozzle Locking Lever is in the UP position.
2. Remove the valve cap from the tire valve stem.
3. Attach the compressor air valve nozzle onto the tire air valve stem and push down the air valve
nozzle as far as it travels. Make certain it is seated properly.
4. Press down the Nozzle Locking Lever all the way down to securely lock the tire air valve stem.
IMPORTANT: If the tire is completely deflated, raise the vehicle by utilizing a recommended rated
lifting device and jack stand before inflating the tire.
5. Turn the compressor switch located on the front panel of Boost 200 to ON position.
6. Monitor the pressure on the compressor air pressure gauge while inflating.
7. Turn OFF the compressor when the desired tire air pressure is reached.
8. Disconnect the air hose nozzle from the tire air valve stem by lifting Nozzle Locking Lever to the UP
position.
9. Replace the tire valve cap onto the tire valve stem.
10. Stow the air hose into the Compressor Air Hose Compartment.
11. Turn the Main Booster Power Switch to OFF position when the system is not in use.
B. TO INFLATE BALLS/AIR MATTRESSES/RUBBER RAFTS:
IMPORTANT: Turn the Main Booster Power Switch to ON position. The LED indicator located
in the front panel will illuminate BLUE indicating power is available in the Boost 200 system.
1. Open the Compressor Air Hose Compartment access door at the left side of the Boost 200 and pull
out the air hose. Make sure that the Nozzle Locking Lever is in the UP position.
2. Remove the valve cap from the inflatable valve stem.
3. Attach the appropriate valve stem adaptor to the Air Hose Nozzle.
4. Press down the Nozzle Locking Lever all the way down to securely lock the valve stem adaptor.
5. Attach the compressor air valve nozzle with the valve stem adaptor onto the air valve stem of the
inflatable and push down the air valve Nozzle as far as it travels. Make certain it is seated properly.
6. Turn the compressor switch located on the front panel of Boost 200 to ON position.
7. Monitor the pressure on the compressor air pressure gauge while inflating.
8. Turn OFF the compressor when the desired air pressure is reached.
9. Disconnect the air hose nozzle from the air valve stem.
6. Replace the valve cap onto the valve stem.
7. Stow the air hose into the Compressor Air Hose Compartment.
8. Turn the Main Booster Power Switch to OFF position when the system is not in use.
12 VOLT DC POWER PORT OPERATING INSTRUCTIONS:
IMPORTANT: The Internal auto-reset Circuit Breaker will automatically interrupt the power if the current
drawn exceeds 10Amp.This feature prevents damage to the Boost 200 internal circuits. Internal Circuit
Breaker will automatically reset after cooling period (Approximately 10-25 minutes)
Model No. 2032
Sheet 4 of 9
