Mamiya 7 User Manual

Light shield curtain closing lever
mark indicates that the curtain is open.
mark indicates that the curtain is closed.
Light shield curtain release
Used to open a closed curtain.
Battery chamber
Stores one of silver-oxide battery (4SR44),
alkaline manganese battery (4L-R44), or
lithium battery (2CR1/3).
Film Rewind Button
(use for 135 type film)
120-220/135 selector index
window
When the pressure plate is aligned with
the film type used, either "120" or "220/
135" is indicated in this window.
Memo clip
Holds the film box top or memo as a film
type reminder.
Back cover
Viewfinder eyepiece
Rubber eyecup
Carrying strap lugs
Film spool stud
Lower cover
Tripod socket
The socket has U1/4"
threads.
5

Mamiya 7 Specifications

General

Type	Rangefinder
Film Format	120/220
Image Size	6x7
Lens Mount	Mamiya 7 mount
Exposure Modes	Aperture priority AE, Manual
