Maintenance and care
21
Refilling with oil
Caution:
Do not add so much engine oil that the
oil level rises above the max. marking
on the dipstick. Overfilling will result in
damage to the engine.
Fill up with fresh engine oil via oil filler
neck (arrow) on cylinder head cover.
After filling start the engine and let it run
for a few minutes at low speed.
Caution:
If no oil pressure builds up after ap-
prox. 10 seconds switch off the engine
immediately.
Check oil pressure and check that there is
no oil leakage.
Then shut down the engine. After about
20 minutes, check the oil level.
D Pull out dipstick
D wipe it with a clean, lintfree cloth
D and push it in again up to the stop
D Pull out dipstick again
The oil level should be between the two
notches in the dipstick and must never fall
below the lower notch. Top up any missing
oil. Do not overfill.
Oil
?
MIN
MAX
