Man L23/30DF User Manual

Adress Hex Bit Meas.
Point
Description Unit Origin Signal
range
MW 122 7A 0
1
2
3
4
5
6
7
8
9
10
11
12
14
15
Alarm TAH21 : Lube oil temperature filter inlet high
Alarm PAL23 : Lube oil pressure TC low
Alarm PDAH40-43 : Diff. pressure fuel oil filter high
Alarm PAL40 : Fuel oil pressure engine inlet low
Alarm PAL70 : Start air pressure low
Alarm TAH98-1 : Alternator winding temp. L1 high
Alarm TAH98-2 : Alternator winding temp. L2 high
Alarm TAH98-3 : Alternator winding temp. L3 high
Alarm TAH29-1 : Alternator front bearing temp. high
Alarm TAH29-2 : Alternator rear bearing temp. high
Alarm : OMD
Alarm : CCMON
Alarm : TC Overspeed
Alarm: Cylinder Lubrication Error
Alarm: Prelube pressure low
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
CMS
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
binary
MW 123
MW 124
7B
7C
0
1
2
3
5
Alarm ZX92 : OMD system failure
Alarm ZX27-29 : CCMON system failure
Alarm: VIT positioning Error
Alarm: CAN 3 Error - VIT communication Error
Alarm: Jet System Error
Operating hour counter
DM
DM
DM
DM
DM
CMS
binary
binary
binary
binary
binary
0..65535
MW 125 7D Overload hour counter h CMS 0..65535
MW 126 7E 0
1
Load reduction request: VIT emergency mode error
Load reduction request overridden : VIT emerg.
mode error
active=1
active=1
DM
DM
binary
binary
MW 127 7F Start of spare
MW 1799 707 End of spare
MAN Diesel & Turbo
3700054-4.0
Page 5 (5)
Modbus list
B 19 00 0
L27/38S, L16/24S, L21/31S, L16/24, L21/31, L27/38
2015.11.27
