9 Scope of supply
9.1 Delivery Scope, VTA and Equipment
The equipment and scope of supply for the adjustable turbine nozzle ring
may vary depending on the specific application. The following tables list
which components are included in the scope of supply of MAN Die-
sel & Turbo and which components must be procured by the customer.
VTA Variable Turbine Area
VCS VTA Control System
MPC Multi Purpose Controller
MOP Main Operating Panel
SACS Scavenging Air Control Software
ECS Engine Control System
9.2 Hardware
VTA Two-stroke diesel engine Four-stroke diesel
engine
Stand-alone
Scope of supply
Hardware
MC
MC-C
ME
ME-C
ME-B
Adjustable turbine nozzle
ring
● ● ● ●
Adjustment device ● ● ● ●
Sealing air system ● ● ● ●
Feed pipe to sealing air sys-
tem
EB EB EB EB
Cooling water system ● ● ● ●
Cooling water system supply
and discharge pipes
EB EB EB EB
Servomotors ● ● ● ●
VCS ● ● - ●
MPC ● EB - -
PC (MOP) ● (●) - -
Monitor with holder (MOP) ● (●) - -
Keyboard (MOP) ● (●) - -
Fuel indicator sensor ● EB - EB
Explanation of terms in
tables 1 to 3
9 Scope of supply
9.2 Hardware
2013-12-04 - de
9
MAN Diesel & Turbo
32 (38)
EN-US
