54 CSS-VC-1.6 | 1.01.03 www.mc-techgroup.com
Gas conditioning unit version CSS-VC..
(C) Consumable parts,
(R) Recommended spare parts
(S) Spare parts
Recommended quantity
in operation [years]
Article No.
Description
C/R/S
1
2
3
Aerosol filter CLF5
90F2005
Filter element type CLF-5 for liquid particulate
filters CLF and CLF-5.
R
1
2
3
90F0040
O-ring (26) for the filter head. Material: Viton.
R
1
2
3
90F3530
CLF-5/W Spare parts set I, filter frit, membrane
filters, flat ring washer, O-ring.
R
1
2
3
Sample gas pump N3/5/9
90P2120
Moulded diaphragm type S3, for N3-N5 KPE,
material: Viton
®
/PTFE.
C
1
2
3
90P2111
Valve reed type V3 with O-ring type O3, for N3-
N5, 1 pc, material: Viton (2 pieces required)
C
2
4
6
90P2220
Moulded diaphragm type S9 for N9 KPE,
material: Viton
®
/PTFE.
C
1
2
3
90P2211
Valve plate with gasket for N9 KPE, 1 piece,
material: Viton
®
.
C
2
4
6
Peristaltic pump SR25.2:
90P1007
SR25 pump hose with PVDF hose connector DN
4/6 mm
C
1
2
4
90P1010
1 set of pressure springs for roller support of
SR25.2 (set = 4 pieces)
C
1
2
3
90P1020
Roller support complete for SR25.2
R
-
-
1
90P1045
Pressure roller (1 pc.) for SR25.2
C
-
2
4
90P1050
Belt for SR25.2
S
1
1
1
90P1025
S-lock for SR25.2
S
1
1
1
90P1031
Hose pump head complete for SR25.2 without
synchronous motor and transmission
S
1
1
1
Flow meter FM40:
90A0015
Flow meter glass for FM40
Measuring range 7-70 l/h air
S
-
1
1
94F0010
Flow meter glass for FM40
Measuring range 15-150 l/h air
S
-
1
1
94F0015
Flow meter glass for FM40
Measuring range 25-250 l/h air
S
-
1
1
90A0018
Viton O-ring 9 for FM40 glass
R
2
4
6
Miscellaneous:
90G0030
Fuse 6.3 A T (time-lag), 5 x 20 mm for CSS...
R
5
5
5
Hose and hose fittings:
05V3215
Bulkhead union SV-PVDF DN 4/6
R
2
2
2
05V6600
Clamping ring 4/6 PVDF see above.
R
5
10
10
05V6605
Nut M10-4/6 PVDF see above.
R
5
10
10
02B1000
PTFE hose NW 4/6 (m)
S
1
2
3
10T1000
Tubing cutter
S
1
1
1
