CHARACTERISTICS 100 SC2, 120 SC2 & 140 SC

(1) (3)(2)

LOAD SPECIFICATIONS UNIT 100 SC-2 120 SC-2 140 SC TOL ±

Lifting platform

Nominal capacity for use indoor (Wind 0 Km/h)

Nominal capacity for use outdoor (Wind 45 Km/h)

680 (1) 454 (1) 363 (1) -

136 (2) 136 (2) 136 (2) -

544 (3) 318 (3) 227 (3) -

No. of people in the basket during indoor use

4 (1) 4 (1) 3 (1) -

1 (2) 1 (2) 1 (2) -

3 (3) 3 (3) 2 (3) -

No. of people in the basket during outdoor use

4 (1) 2 (1) 2 (1) -

1 (2) 1 (2) 1 (2) -

3 (3) 1 (3) 1 (3) -

Lifting platform unladen weight Kg 3309 3490 4647 20

Slope rating

Outriggers in/out ° 3 / 3 3 / 3 3 / 3 0,1

Side slope rating

Outriggers in/out ° 2 / 0,8 2 / 0,8 2 / 0,8 0,1

Traversable slope % 40 35 35 2

Work speed Km/h 0,5 0,5 0,5 0,1

Fast transport speed Km/h 5.6 5.6 5.6 0,2

Fast transport speed (max torque) Km/h 1.4 1.4 1.4 0.1

Wheels

Weight of a wheel Kg 80.5 80.5 80.5 3,4

Max load on one wheel Kg 1332 1409 1731 5

Contact surface on the ground (hard / soft ground)

Cm² - / - - / - - / - 3

Ground punch-through (Wheel / Stab) daN/Cm² 5.14 / 2.63 5.44 / 2.78 6.76 / 3.46 -

LwA acoustic power level db 105 105 105 -

Sound pressure level at workstation

Platform db 79 79 78 -

Ground db 85 85 85 -

647367 (01/03/2017)

100/120 SC-2 / 140 SC

Manitou 100 SC-2 User Manual
