2-32
USING THE LIFTING PLATFORM
MOVEMENT IN TRANSPORT / WORK MODE
- The lifting platform has two separate movement modes: Transport mode (Fig. B) and Work mode (Fig. C). Direction of forward movement
: Fig. A.
- Transport mode: the platform’s scissor assembly is in the Low position. This mode enables you to travel at high speed (see the
CHARACTERISTICS Section).
- Work mode: the scissor assembly is raised. In this mode, translations are made at slow speed.
In Work mode, any movement over broken ground, loose surfaces, slopes greater than the authorised level of tilt (see the
CHARA
CTERISTICS section) likely to overturn or unbalance the lifting platform is PROHIBITED.
In the case of a steep slope: - no load in the basket; use reverse gear.
FORWARD
TRANSLATION
REVERSE
TRANSLATION
TRANSPORT MODE
B
A
WORK MODE
C
647367 (01/03/2017)
100/120 SC-2 / 140 SC
