2-12
DIMENSIONS 100 SC2, 120 SC2, 140 SC
100 SC-2 120 SC-2 140 SC
A 3760 mm
B 2290 mm
C 2790 mm
C1 1530 mm
D 1750 mm
E 1600 mm
F 2590 mm 2590 mm 2740 mm
F1 1920 mm 1920 mm 2080 mm
G 2110 mm
H 4600 mm
647367 (01/03/2017)
100/120 SC-2 / 140 SC
