2-8
CHARACTERISTICS 100 SC2, 120 SC2 & 140 SC
(1) (3)(2)
LOAD SPECIFICATIONS UNIT 100 SC-2 120 SC-2 140 SC TOL ±
Lifting platform
Nominal capacity for use indoor (Wind 0 Km/h)
Nominal capacity for use outdoor (Wind 45 Km/h)
Kg
680 (1) 454 (1) 363 (1) -
136 (2) 136 (2) 136 (2) -
544 (3) 318 (3) 227 (3) -
No. of people in the basket during indoor use
4 (1) 4 (1) 3 (1) -
1 (2) 1 (2) 1 (2) -
3 (3) 3 (3) 2 (3) -
No. of people in the basket during outdoor use
4 (1) 2 (1) 2 (1) -
1 (2) 1 (2) 1 (2) -
3 (3) 1 (3) 1 (3) -
Lifting platform unladen weight Kg 3309 3490 4647 20
Slope rating
Outriggers in/out ° 3 / 3 3 / 3 3 / 3 0,1
Side slope rating
Outriggers in/out ° 2 / 0,8 2 / 0,8 2 / 0,8 0,1
Traversable slope % 40 35 35 2
Work speed Km/h 0,5 0,5 0,5 0,1
Fast transport speed Km/h 5.6 5.6 5.6 0,2
Fast transport speed (max torque) Km/h 1.4 1.4 1.4 0.1
Wheels
Weight of a wheel Kg 80.5 80.5 80.5 3,4
Max load on one wheel Kg 1332 1409 1731 5
Contact surface on the ground (hard / soft ground)
Cm² - / - - / - - / - 3
Ground punch-through (Wheel / Stab) daN/Cm² 5.14 / 2.63 5.44 / 2.78 6.76 / 3.46 -
LwA acoustic power level db 105 105 105 -
Sound pressure level at workstation
Platform db 79 79 78 -
Ground db 85 85 85 -
647367 (01/03/2017)
100/120 SC-2 / 140 SC
