2-9
HYDRAULIC MOVEMENT (basket control) UNIT 100 SC-2 120 SC-2 140 SC TOL ±
Plat-form movement
Raising max laden s 29 to 39 34 to 44 56 to 66 5
Lowering max laden s 26 to 36 24 to 34 26 to 36 5
INTERNAL COMBUSTION ENGINE UNIT 100 SC-2 120 SC-2 140 SC TOL ±
Type KUBOTA D1105 Tier 4 -
Fuel Gasoil Gasoil Gasoil -
No. of cylinders 3 3 3 -
Cubic capacity Cm3 1,123 1,123 1,123 -
dling speed, unladen tr/mn 1500 1500 1500 -
Max engine revs, unladen tr/mn 3000 3000 3000 -
ISO power/ rpm (at 3000 rpm) CV - KW 24.8 - 18.5 24.8 - 18.5 24.8 - 18.5 -
Max torque (at 2200 rpm) Nm 71,5 71,5 71,5 -
Unladen weight Kg 93 93 93 5
Air filtration µm - - - -
Type of cooling eau eau eau -
Fan ----
TRANSMISSION UNIT 100 SC-2 120 SC-2 140 SC TOL ±
No. of steered wheels
front / rear 2 / 0 2 / 0 2 / 0 -
No. of driven wheels
front / rear 2 / 2 2 / 2 2 / 2 -
Axle / Front wheel
Différential NO -
Pneumatic 26 x 12 x 380 -
Axle / Rear wheel
Différential NO -
Pneumatic 26 x 12 x 380 -
LEVEL OF VIBRATIONS UNIT 100 SC-2 120 SC-2 140 SC TOL ±
Vibrations received by the hands, arms and
body combined
m/s² 2,5 2,5 2,5 -
Quadratic average values for the body m/s² < 0,5 < 0,5 < 0,5 -
647367 (01/03/2017)
100/120 SC-2 / 140 SC
