Manitou 140 SC - MAINTENANCE TABLE; IC Engine Maintenance Schedule

3-10
MAINTENANCE TABLE
(1): COMPULSORY OVERHAUL AFTER 500 HOURS or 6 MONTHS
This overhaul must compulsorily be performed after approximately the first 500 hours of operation or 6 months after
the machine is put into service (when the earlier of the two periods is reached).
(2): The engine oil and the engine oil filter must be replaced after the first 50 hours of operation, and then every 500
hours of operation.
A = REGULATE, C = CHECK, G = GREASE,
N = CLEAN,
P = BLEED, R = REPLACE, V = DRAIN
PAGE
(1)
DAILY OR EVERY
10 HOURS OF
OPERATION
EVERY 50 HOURS
OF OPERATION
EVERY 250 HOURS
OF OPERATION
EVERY 500 HOURS
OF OPERATION OR
6 MONTHS
EVERY 1000 HOURS
OF OPERATION OR
1 YEAR
EVERY 2000 HOURS
OF OPERATION OR
2 YEARS
EVERY 40000
HOURS OF
OPERATION
OCCASIONAL
IC ENGINE
Engine oil level
3-12 C C <<< <<< <<< <<< <<< <<<
Coolant level 3-12 C C <<< <<< <<< V <<< <<<
Fuel level 3-12 C C <<< <<< <<< <<< <<< <<<
Dry air filter cartridge 3-17/22 R C/N <<< R <<< <<< <<<
Radiator core 3-17 N N <<< <<< <<< <<< <<<
Alternator / crankshaft / fan belt tensioning 3-19 C/A C/A <<< <<< <<< <<<
Fuel filter 3-14/19 R N R <<< <<< <<<
Engine oil (2) 3-22 V V <<< <<< <<<
Engine oil filter (2) 3-22 R R <<< <<< <<<
Injectors C** <<< <<< <<<
Fuel tank 3-24 N <<< <<<
Dry air filter safety cartridge 3-22 R <<< <<<
Engine silentblocks C** <<< <<<
Engine rpm C** <<< <<<
Radiator C** <<< <<<
Valve play C** C** <<<
Water pump and thermostat C** <<<
Alternator and starter C** <<<
Fuel feed circuit 3-29 P
TRANSMISSION
Braking
3-13 C C <<< <<< <<< <<< <<< <<<
TYRES
Tightening the wheel nuts
3-13 C C <<< <<< <<< <<< <<< <<<
Condition of the tyres & wheels 3-13 C C <<< <<< <<< <<< <<< <<<
Wheel 3-29 R
LIFTING STRUCTURE
Overload
C <<< <<< <<< <<<
HYDRAULIC SYSTEM
Hydraulic oil
3-13/23 C C <<< <<< V/R <<< <<< <<<
Hydraulic movement speeds C** <<< <<<
State of the hoses C** <<< <<<
State of the cylinders (leaks, rods) C** <<< <<<
Hydraulic circuit pressures C** <<<
Hydraulic circuit flow rates C** <<<
Hydraulic oil reservoir N** <<<
647367 (01/03/2017) 100/120 SC-2 / 140 SC
