Manitou MHT 7140 T-E3 User Manual

3-32
D8 - DRY AIR FILTER CARTRIDGE
CHANGE
In case of use in a heavily dust laden atmosphere, there are pre-filtration cartridges, see: 3 -
MAINTENANCE: FILTERS CARTRIDGES AND BELTS. Also, the checking and cleaning periodicity
of the cartridge must be reduced (up to 250 hours in a heavily laden dust atmosphere and
with pre-filtration).
Change the cartridge in a clean location, with the I.C. engine stopped. Never operate the lift truck with the
air filter removed or damaged.
- Open the I.C. engine bonnet.
- Loosen the bolts and remove cover 1 (fig. D8/1).
- Gently remove the cartridge 2 (fig. D8/2), taking care to avoid spilling the dust.
- Leave the safety cartridge in place.
- The following parts must be cleaned with a damp, clean lint-free cloth.
• The inside of the filter and cover.
• The inside of the filter inlet hose.
• The gasket surfaces in the filter and in the cover.
- Check pipes and connections between the air filter and the I.C. engine and the connection
and state of the clogging indicator on the filter.
- Before mounting check the state of the new cartridge (see: 3 - MAINTENANCE: FILTERS
CARTRIDGES AND BELTS).
- Introduce the cartridge into the filter axis and push it in, pressing the edges and not the
middle.
- Reassemble the cover, guiding the valve downwards.
D8/1
1
2
D8/2
