Manitou MHT 7140 T-E3 - Braking Oil and Windscreen Washer Tank Access Panel; Windscreen Washer Tank Access Panel; Steering Wheel Regulating Handle; Door Lock

2-41
24 - BRAKING OIL AND WINDSCREEN WASHER TANK ACCESS PANEL
MHT 7140-E3
MHT 10160 LT-E3
- Loosen screw 1 and lift up the braking oil and windscreen washer tank access panel
(see: 3 - MAINTENANCE: B - EVERY 50 HOURS OF SERVICE).
24 - WINDSCREEN WASHER TANK ACCESS PANEL
MHT 10210 LT-E3
- Loosen screw 1 and lift up the braking oil and windscreen washer tank access panel
(see: 3 - MAINTENANCE: B - EVERY 50 HOURS OF SERVICE).
25 - STEERING WHEEL REGULATING HANDLE
This handle enables the angle and height of the steering wheel to be adjusted.
- Pull handle 1 to adjust the steering wheel.
- Push in handle 1 to lock the steering wheel in the desired position.
26 - DOOR LOCK
Two keys are provided with the lift truck to enable the cabin to be locked.
27 - LOCKING HANDLE FOR UPPER HALF-DOOR
28 - UNLOCKING BUTTON FOR UPPER HALF DOOR
29 - HANDLE FOR REAR WINDOW OPENING
EMERGENCY EXIT
Use the rear window as an emergency exit, in the event that it is impossible to leave the cab by
the door or by opening the windscreen.
NOTE: There is an OPTIONAL rear window stay.
1
1
