G5 - LIFT TRUCK
SLING
- Take into account the position of the lift truck centre of gravity for lifting (fig.
G5/1).
A = 2007 mm B = 1393 mm MHT 7140 T-E3
A = 2183 mm B = 1467 mm MHT 10180 LT-E3
A = 2450 mm B = 1200 mm MHT 10225 LT-E3
- Place the hooks in the fastening points provided (fig. G5/2 and G5/3).
G4/1
G5/3
G5/2
G5/2
G5/1G5/1
AB
G5/1G5/1
AB
G5/2
MHT 10180 LT-E3
MHT 10225 LT-E3
MHT 7140 T-E3
