2-13
SPECIFICATIONS AND WEIGHTS
Speed of movement for lift truck in standard configuration on flat
ground (except particular conditions)
Front unladen km/h
25
laden km/h 8
Rear unladen km/h 25
laden km/h 8
Rated capacity with standard attachment kg 22500
Standard lifting height kg 9700
Standard attachment forks PFB
Fork dimensions (length x width x thickness) mm 1800 x 200 x 100
Distance from the centre of gravity from the load to the lug of the forks
mm 900
Weight with standard attachment
Unladen kg 29800
At rated load kg 52300
Weight per axle with standard attachment (transport position)
Front unladen kg
9670
Rear unladen kg 20130
Drag strain on the coupling hook
Unladen (sliding) daN
-
At rated load (transmission setting) daN 17400
Pull strain with open carrier
(according to standard ISO 8313)
daN -
HYDRAULIC MOVEMENTS
Longitudinal stability limiter and warning device Electronic
Lifting motions (boom retracted)
Unladen lifting s - m/mn
-
Unladen lowering s - m/mn -
Telescoping motions (boom raised)
Unladen extending s - m/mn
-
Unladen retracting s - m/mn -
Tilting movements
Unladen digging s - °/s
-
Forward tilting unladen s - °/s -
HYDRAULIC CIRCUIT
Hydraulic pump
Type Gear pump
1st casing
Capacity cm3 75
Max. rating capacity unladen l/mn 170
Flow rate at 1600 rpm l/mn 120
Maximum service pressure bar
350
Telescoping circuit bar 290 / 350
Lifting circuit bar 320 / 320
Tilt circuit bar 200 / 350
Attachment circuit bar 270
Steering circuit bar 200
SOUND AND VIBRATION
Level of sound pressure in the driver’s cab LpA
(according to standard NF EN 12053)
dB 79,2
Level of sound power ensured in the LwA environment
(according to directive 2000/14/EC modified by directive 2005/88/EC)
dB
106 (measured)
108 (ensured)
Average weighted acceleration on driver’s body
(according to standard NF EN 13059)
m/s2
The average weighted acceleration transmitted to the driver’s hand/arm system
(according to standard ISO 5349-2)
m/s2 < 2,5
