2-27
GEAR BOX OIL TEMPERATURE LAMP
This lamp comes on when the temperature of the gear box oil is abnormally high. In this case, place the forward/reverse
selector in neutral and let the I.C. engine running at idle for a few minutes. If the lamp remains on, stop the lift truck and
contact your dealer.
NOTE: Abnormal heating of the oil may be linked to an incorrect use of the gear box ratios (see: 2 - DESCRIPTION: 21 - GEAR
LEVER).
PARKING BRAKE LAMP
This lamp comes on when the parking brake is applied.
HYDRAULIC MOVEMENT NEUTRALISATION LAMP
The lamp lights when the hydraulic controls are neutralised and when a forbidden hydraulic movement is requested.
6C - PANEL FOR BUTTONS AND KEYBOARD
A beep is sounded each time one of the buttons is pressed.
“BUCKET” MODE (NOT USED)
See: 2 - DESCRIPTION: 7 - LONGITUDINAL STABILITY LIMITER AND WARNING DEVICE.
OPTION PROGRESSIVE TRANSMISSION “INCHING” MODE
STANDARD TRANSMISSION MODE (default mode)
OPTION PROGRESSIVE TRANSMISSION “INCHING” MODE IN FORWARD AND REVERSE GEAR (OPTION)
The indicator
on the instrument control panel will light when it is in use.
- The operating screen displays the enabled mode. Press the button to display the other available mode(s).
CHANGE MODE
88°
88
ON TYRES
Press
1
Confirm
Cancel
88°
88
ON TYRES
Press
1
Confirm
Cancel
“SUSPENDED LOAD” MODE
See: 2 - DESCRIPTION: 7 - LONGITUDINAL STABILITY LIMITER AND WARNING DEVICE.
